Running WebAssembly on Kubernetes with Kwasm

For the longest time, the WebAssembly (Wasm) ecosystem has suffered from a lack of tooling that makes the process of deploying Wasm apps simple, in contrast to the container ecosystem, which provides a myriad of ways to build, deploy, and scale your applications.

In this tutorial, we will explore WebAssembly and how you run your WebAssembly workloads on the planet's most popular container orchestrator using Kwasm.

An Introduction to Wasm and Containers

Before we dive into the tutorial, I want to briefly dive into the concepts of WebAssembly and Containers to help you understand the difference between the two.

What is the difference between WebAssembly and Containers?

WebAssembly (Wasm) and containers may seem like competing technologies, but they serve different purposes and can complement each other in modern application architectures.

Do Wasm apps run as Containers?

Despite these differences, both WebAssembly and containers embrace the Open Container Initiative (OCI) standards for packaging and distribution. This means that while a WebAssembly module and a container image are fundamentally different, they can be packaged and distributed using the same tools and infrastructure.

Later in this post, we'll demonstrate how to run a WebAssembly application on Kubernetes as if it were a container. This is possible because both technologies adhere to OCI standards, allowing for integration into existing container workflows and orchestration platforms.

WebAssembly with Kwasm

Kwasm is an open-source project that enables users to run webassembly workloads on Kubernetes, Kwasm takes care of the cumbersome process of bootstrapping nodes and provides custom resource definitions for creating a runtimeclass for running wasm applications.

Prerequisites

To follow along with this portion of the tutorial, you will need the following installed:

• A Civo Account
• Kubectl installed
• Helm

Launching a new Cluster

If you haven’t already, you will need to create a new Kubernetes cluster in order to follow along:

Create a 2-node cluster:

1civo k3s create --create-firewall --nodes 2 -m --save --switch --wait kwasm

This will launch a 2 node Kubernetes cluster within your Civo account.

Installing Kwasm

Preparing your cluster to run WebAssembly typically involves a lengthy bootstrap process of ssh’ing into your nodes, installing the Wasm Runtime on worker nodes, and updating a few config files here and there thankfully, the Kwasm operator abstracts this process and allows us to install the operator with a single helm command.

Install Kwasm using Helm:

Add the Kwasm repo:

1helm repo add kwasm http://kwasm.sh/kwasm-operator/

Install the Kwasm chart:

1helm install -n kwasm --create-namespace kwasm-operator kwasm/kwasm-operator

Next, annotate the nodes you would like to run wasm workloads on. For the purpose of this demonstration, we will annotate all nodes in this cluster:

1kubectl annotate node --all kwasm.sh/kwasm-node=true

Create a RuntimeClass

Next, we need to set up a RuntimeClass for our WebAssembly workloads. RuntimeClasses in Kubernetes allow us to specify different container runtimes for scheduling pods. This is crucial for running WebAssembly, as it requires a runtime different from that of traditional containers.

For those unfamiliar, a container runtime is the software responsible for running containers. In this case, we're setting up a special runtime that can handle WebAssembly modules instead of traditional container images:

1echo '
2  apiVersion: node.k8s.io/v1
3  kind: RuntimeClass
4  metadata:
5    name: wasmtime-spin
6  handler: spin' | kubectl apply -f -

Creating a WebAssembly deployment

Now that we have our RuntimeClass set up, let's create a deployment for our WebAssembly application. We'll use a simple "hello world" example written in Rust and compiled into WebAssembly.

Here's the command to create our deployment:

1echo '
2  apiVersion: apps/v1
3  kind: Deployment
4  metadata:
5    name: wasm-spin
6  spec:
7    replicas: 1
8    selector:
9      matchLabels:
10        app: wasm-spin
11    template:
12      metadata:
13        labels:
14          app: wasm-spin
15      spec:
16        runtimeClassName: wasmtime-spin
17        containers:
18        - name: spin-hello
19          image: ghcr.io/deislabs/containerd-wasm-shims/examples/spin-rust-hello:latest
20          command: ["/"]
21' | kubectl apply -f -

Remember, other than the runtimeClassName specification, this looks just like a regular Kubernetes deployment. We're using a pre-built WebAssembly module packaged as an OCI image. This image contains a simple "hello world" application written in Rust and compiled to WebAssembly.

Testing the deployment

To test the deployment, run the following command to port-forward the deployment we just created:

1kubectl port-forward deployment/wasm-spin 8000:80

Make a request to the service using curl:

1curl localhost:8000/hello

Your output should be similar to:

1Hello world from Spin!

Closing thoughts on the WebAssembly ecosystem on Kubernetes

The WebAssembly ecosystem is undoubtedly maturing, but it's important to recognize that it's still in its early stages compared to more established technologies like containers. The journey to seamlessly integrate WebAssembly with Kubernetes has been an evolving one.

A few short years ago, a project called Krustlet aimed to solve the problem of running WebAssembly on Kubernetes using a Rust-based runtime. Krustlet has since been archived.

In this tutorial, we leveraged Kwasm, a more recent solution for running WebAssembly workloads on Kubernetes. However, it's crucial to note that the maintainers currently recommend against using it in production environments due to potential risks to nodes. That said, progress is being made, and some cloud providers are already offering support of which Civo is among the supported providers according to the Kwasm compatibility list.

If you're intrigued by the potential of WebAssembly on Kubernetes and want to dive deeper. Check out this post that explores the benefits in more detail into how WebAssembly can enhance performance in Kubernetes environments.

Looking to dive deeper into Wasm on Kubernetes? The spin-operator project provides a more robust feature set and uses Kwasm under the hood. While the tooling for WebAssembly in Kubernetes environments may not yet be as user-friendly or mature as the container ecosystem, the rapid progress and growing interest in this technology are undeniable.
